1, M-PPG– 2/1000 Pulse Peak: 2KV Pulse Polarity: Positive Pulse Rise Time: 600ps Pulse Width [ FWHM]: 1.5ns Max repetition: 1MHz Jitter ( RMS): 20ps Spectrum range ( -6dB ): 300MHz Mean output power: 100W Output Connector: N Type Input triggering connector: SMA Type Triggering pulse: +5V, 10..50ns width Power Supply: DC +105V, 2A ; DC +18V,2A SIZES: W250x H110x Depth 72
2, M– PPG– 4/100 Pulse Peak: 4KV Pulse Polarity: Positive Pulse Rise Time；600ps Pulse Width ( FWHM )：1.5ns Max repetition rate: 100KHz Jitter ( RMS) : 30ps Spectrum range ( -6dB) : 300MHz Mean output power: 40W Output Connector: N –TYPE; Input triggering connector: SMA Type Triggering pulse: +5V, 10..50ns Width Power Supply: DC +150V,1A; DC+18V,1A SIZES: W250xH23xDpeth 110
3, M– PI-5/100 Pulse Inverter Pulse Peak: 5KV Input pulse polarity: both Max input pulse Width: 100ns Module of voltage transfer ratio : > 0.95 Square pulse top skew: < 6%/100ns Input /output Connectors: N type SIZES: W190xH28x Depth 48
4， M-NPG– 18/3500(N) Pulse Peak : Regulated 12– 20KV @75ohm load up to 40KV at discharged reactor. Pulse Polarity: Positive - 18/3500, Negative - 18/3500N Pulse Rise Time: < 4ns Max Pulse Energy: 30mJ Peak Pulse Power: 5.3MW Repetition rate: from single pulse to 3.5KHz [ single pulse mode in case of external triggering only ] Inherent delay； 1us or less. Jitter (RMS): Less than 1ns Special output connector for HV applications. Internal and external triggering. BNC connectors for external triggering and pulse monitoring. SIZES: W248X H90X Depth
5, M-NPG– 18/100K Pulse Peak: Regulated 13...18KV @ 75ohm load, up to 36KV on discharge Polarity: Positive –18/100K, Negative –18/100KN Pulse Rise Time: < 4ns Width ( FWHM ): less than 10ns Pulse energy: regulated 15… 30mJ Repetition rates and operation modes: Continuous : from 1Hz to 4KHz Burst: from 1Hz to 100KHz single pulse ; burst length : from 1 to 4000 Internal delay: 1.2 us or less Jitter ( RMS ) : 1ns Internal and external triggering Special output HV coaxial connector, SNYC IN and SYNC OUT BNC connectors Power Supply: AC110...230V/ 50...60Hz Single pulse mode for external triggering only SIZS: W248xH90xDepth
|
|
介绍照片或图形的题注。 |
各种皮秒、纳秒、微秒脉冲源及宽带脉冲极性变换器 |
|
公司提供定制各种皮秒、纳秒脉冲源 |
